Introduction of Standard Sintered Mesh
Usually standard sintered mesh consists five layers,the protective
layer,the filter layer,the dispersion layer and two reinforcing
meshes.It provides excellent performances such as high precision
and strength,so it is ideal filter medium for applications
requiring high strength and precision.
Thanks to its surface filtration construction,and smooth wire of
the mesh,it is good at backwashing and regeneration.Therefore,it
can be reused for along time,and is especially suitable for
continuous and automatic operation,which exc-eeds any other kind of
filter material.
Furthermore,this mesh is easy to be formed,machined and welded.It
can be produced into many kinds of shapes such as
circular,cartridge,cone and pleats.
Features
1.High filtration accuracy, stable aperture, small pressure loss,
aperture does not change with pressure. It can effectively remove
suspended matter and particles, with good filtration precision and
purification effect.
2.High porosity, uniform and smooth pores, small initial
resistance, easy backwash, strong regeneration ability, long
service life, especially suitable for fluid distribution,
homogenization treatment and other occasions requiring high
uniformity.
3.High mechanical strength, good rigidity, good plasticity,
oxidation resistance, corrosion resistance, do not need additional
skeleton support protection, easy installation and use, easy
maintenance, good assembly, can be used for welding, bonding,
processing.
Specification
1.material: SS316L
2.Size:1200*1000mm
3.Special specification can be made on your request
Parameters
construction | Protective Layer |
| Filter Layer |
| Dispersion Layer |
| Reinforcing Layer |
| Reinforcing Layer |
| type | nominal precision(um) | absolute accuracy(um) | air permeability (L/min ·cm2·pa) | bubble point pressure(pa) |
| AI1 | | 6-7 | | 5300-6000 |
| AI2 | 2 | 8-9 | (1-6)×10-4 | 4300-5000 |
| AI5 | | 11-13 | (6-10)×10-4 | 3000-3700 |
| AI10 | 10 | 16-18 | (6-10)×10-4 | 2700-3300 |
| AI15 | 15 | 24-26 | (1-6)×10-3 | 2000-2600 |
| AI20 | 20 | 28-32 | (1-6)×10-3 | 1800-2300 |
| AI25 | 25 | 34-36 | (6-10)×10-3 | 1400-1900 |
| AI30 | 30 | 40-45 | (6-10)×10-3 | 1200-1700 |
| AI40 | 40 | 50-55 | (1-6)×10-2 | 1000-1500 |
| AI50 | 50 | 71-80 | (1-6)×10-2 | 900-1200 |
| AI70 | 70 | 80-95 | (6-10)×10-2 | 700-1100 |
| AI100 | 100 | 110-120 | ≥5×10-2 | 650-1000 |
Applications
1.Petrochemical industry of high temperature gas filtration;
2.Steam removal of impurities filtration, material decarbon
filtration and fine filtration ultrafine crystal catalyst
filtration washing recovery;
3.Oil field water fine filtration;
4.Metallurgy industry of high temperature flue gas purification;
5.Solid boiling bed exhaust dust recovery;
6.Thermal power generation, nuclear power generation industry dust
and tail gas purification;
7.The precision filtration of liquid products,liquid raw
materials,pharmaceutical intermediates in the chemical industry.
Related Photos
Product Advantages
1.High temperature resistance.
2.High corrosion resistance.
3.Easy to backwash,reusable.
4.High precision.
5.High strength.
